The Visual-Inertial-Dynamical Multirotor Dataset

Recently, the community has witnessed numerous datasets built for developing and testing state estimators. However, for some applications such as aerial transportation or search-and-rescue, the contact force or other disturbance must be perceived for robust planning and control, which is beyond the capacity of these datasets. This paper introduces a Visual-Inertial-Dynamical (VID) dataset, not only focusing on traditional six degrees of freedom (6-DOF) pose estimation but also providing dynamical characteristics of the flight platform for external force perception or dynamics-aided estimation. The VID dataset contains hardware synchronized imagery and inertial measurements, with accurate ground truth trajectories for evaluating common visual-inertial estimators. Moreover, the proposed dataset highlights rotor speed and motor current measurements, control inputs, and ground truth 6-axis force data to evaluate external force estimation. To the best of our knowledge, the proposed VID dataset is the first public dataset containing visual-inertial and complete dynamical information in the real world for pose and external force evaluation. The dataset and related files are open-sourced.

IEEE International Conference on Robotics and Automation
